This free, web-based, easy-to-use coordination tool makes transformer fuse selection effortless. By simply inputting a few pieces of data fields and selecting the desired level of protection, you can quickly find the right Eaton's Cooper Power series ELSP, MagneX Interrupter or Bay-O-Net fuses for your application. The TransFusion Coordination Program provides you the flexibility of trying various combinations before deciding on the one that best fits your application needs. A simple click of the print button allows you to print your TCC curves and part numbers.

Optimizer 2013 is a program that assists users, specifiers, students, sellers, and almost anyone involved in distribution arresters in the selection and understanding of this product.

Functions of the Optimizer program

• Recommends the optimum arrester rating from each manufacturer based on user entered data
• Clearly and easily compares all critical characteristics of Eaton, Joslyn and Ohio Brass distribution arresters

Sources of Data
All of the data in this calculator is public information and found in catalogs, except the Watts Loss data which comes from laboratory tests

Calculation and recommendation methods
The calculation methods are all from IEEE standard C62.22
